*Whilst we make continuous effort to ensure accuracy with the product photo or vehicle shown, please consult an ARB expert if you are unsure if this product is right for you.

PRODUCT CODE: intensity-iq-led-light

Intensity IQ LED Driving Lights

The ARB Intensity IQ has been developed from the ground up, with performance front of mind, whilst delivering a design that complements modern vehicle styling and bar work.

Sold as a Single item

Set Location

Zip Pay Available. Learn More

ARB Intensity IQ Lights - Limitless Control Over Your Driving Lights

FEATURES

Hotspot 1

Super spot—Designed for maximum light capture, the highly refined super spot reflectors provide ultimate illumination distance. With a purposeful reflector design, the free-form shape ensures maximum projection in the toughest conditions.

Hotspot 2

Spot—Designed to harness all available light from the LEDs, the cascading reflector shape and staggered positioning of the lighting elements creates a spot beam tuned for the open road. Partnered with the Super Spot, the Intensity IQ has the best balance of distance and real-world usability.

Hotspot 3

Cast-in ducts—Intelligent thermal management maximises the output in all driving conditions and provides outstanding LED life expectancy. The IQ incorporates cast-in ducts to allow for airflow to pass through the body of the light.

Hotspot 4

Midrange—Using parabolic reflector design the midrange optics have been engineered to provide the best balance of flood and spotlight patterns.

Hotspot 5

Flood—Pushing light out past the periphery of the drivers vision, the flood optics beam is designed to give maximum foreground light in all driving scenarios.

Hotspot 6

Lens design—The shape wraps around the optics across the front of the light however; as it approaches the outer edges it becomes a complex shape that creates it’s own visual drama as the light is viewed from different angles.

Hotspot 7

Lens—Protected by the purpose-driven, virtually indestructible polycarbonate lens, the IQ is contained by a high quality material that will protect your driving light investment.

Hotspot 8

Expertly designed body—Cooling is maximised via the die cast aluminium body which acts as a massive heat sink.

Hotspot 9

Mounting bracket—An innovative, sleek new mounting bracket design not only allows adjustment of light beam angle, but also provides additional mass and surface area for cooling.

CHOOSE FROM THOUSANDS OF BEAM PATTERNS

A unique 4-optic design (Super Spot, Spot, Flood and Midrange) is employed to provide virtually an unlimited choice of light beams to suit any road condition.

The Super Spot and Spot optic, based on free-form reflector technology, produce an even spot beam for extended distance illumination.

The Flood optic has a specially designed lens to maximise the light spread for excellent foreground visibility.

The Midrange optic employs a conventional parabolic reflector to illuminate the midrange area.

SUPER SPOT

Comprised of 4 x Cree XP-P LEDs engineered to provide the furthest projection of light.

SPOT

Designed with 2 x Cree XM-L3 and 3 x XP-P LEDs to provide a broader, yet focused beam of light.

FLOOD

The Flood is made up of 18 x Cree XT-E LEDs, providing optimum peripheral illumination.

MIDRANGE

Contains 4 x Cree XM-L3 LEDs, giving a balance between distance and spread.

CONTROL YOUR ILLUMINATION

To accompany the revolutionary Intensity IQ light, ARB have developed a physical switch controller that is equally as intuitive.

Have access to up to eight different preset configurations at the click of a button, instantly changing the Intensity IQ to your needs. The Intensity IQ controller unlocks a world of possibilities when exploring, presenting premium easy to use tool that will give you choice at the click of a button.

The Intensity IQ control sports a design that is both ergonomic and practical, with users being able to feel and adjust rather than relying on seeing the device itself. The quick select buttons have a definitive edge and when mounted in a hidden position and in the correct orientation, allowing for a quick and easy selection with a positive switching feel.

ARB Intensity IQ App

Finding the right balance of lighting when tackling not only tracks, but also country roads can be challenging. ARB have taken this into account when designing the ARB Intensity IQ app, which allows users to control and set from the thousands of light combinations available with the ARB Intensity IQ lights- straight from your mobile device!

The ARB Intensity IQ app ensures users have the ultimate level of control over the revolutionary ARB Intensity IQ lights. Empowering users to control the brightness levels of each segment (super spot, spot, flood and midrange) from the 20 different levels of light, presents thousands of different combinations to set the perfect illumination for your adventures.

Download the application from the App Store or Google Play.

Download on App Store Download on Google Play

How to adjust the ARB Intensity IQ Lights

DEMANDING MORE ADVENTURES?

Go even further with our extensive range of compatible gears.

Bull Bars

ARB Bull Bars will provide substantially improved protection for vulnerable mechanical components against animal strikes.

SUSPENSION

Old Man Emu produces suspension to suit you, no matter your lifestyle.

Recovery Equipment

ARB’s vehicle recovery accessories are engineered and manufactured to the highest standards, making them ideal for recreational use as well as competition.

VEHICLE LIGHTING

ARB offers one of Australia’s most extensive selections of high-quality vehicle lighting.

Closer Look

The ARB Intensity IQ has been developed from the ground up, with performance front of mind, whilst delivering a design that complements modern vehicle styling and bar work. With a subtle introduction of ARB red within the light, the free-form clear front lens, bezel-less design and CNC machined ARB logo provide a modern, classy and premium new look. Packed with unique features, the Intensity IQ sets a new level of driving light design and usability.
A unique 4-optic design (Super Spot, Spot, Flood and Midrange) is employed to provide virtually an unlimited choice of light beams to suit any road condition. The Super Spot and Spot optics, based on free-form reflector technology, produce an even spot beam for extended distance illumination. The Flood optic has a specially designed lens to maximise the light spread for excellent foreground visibility. The Midrange optics employ a conventional parabolic reflector to illuminate the midrange area. Furthermore, the beam pattern of each of the two lights can be independently adjusted so you could run, for example, one focused on spot and one focused on flood.
